AIRKING COMPRESSOR MANUFACTURER
We are a compressor manufacturer from China. Our factory accepts custom orders for appearance, color, language, parts assigned by brand, etc., and many compressor models are in stock.
motor protection: IP23, IP54, IP65 (oil cooled)
color: grey, blue, red, white, green, yellow, etc. (if your qty good, we can process for your appointed color)
OEM Service: If you have own brand, and we got the authorization from you, we can arrange logo sticker and name plate for you.
Compressor controller Language: English/Spanish/Russian
Warranty: One year warranty for the whole compressor, two years for the compressor airend.
Quality: We will test all the machines one by one before leaving our factory, and also we will share the testing video for customers' reference.
VSD means compressor is varailble speed compressor. VFD compressor can running at variable speed and fixed speed two way.
if inverter have problem, compressor can running at variable speed. its means you have one more fixed speed compressor as reserve use.
VFD can energy saving about 15% than Fixed Speed Compressor.
| MODEL | AKB-10 | AKB-15 | AKB-20 | AKB-25 | AKB-30 |
| Power | KW | 7.5 | 11 | 15 | 18.5 | 22 |
| Capacity | m³/Min/MPa | 0.8~1.1CBM/MIN at pressure 8-13bar | 1~1.7CBM/MIN at pressure 8-13bar | 1.5-2.1 CBM/MIN at pressure 8-13bar | 1.8~2.8 CBM/MIN at pressure 8-13bar | 2.2~3.3 CBM/MIN at pressure 8-13bar |
|
|
|
| Compress Stage | Singel Stage |
| Ambient temperature(℃) | -5℃±45℃ |
| Cooling Method | Air Cooling/Water Cooling |
| Exhaust temperature(℃) | ≤Ambient Temperature + 15 |
| Lubricant | L | 12 | 18 | 18 | 18 | 18 |
| Noise | db(A) | 62±2 | 62±2 | 65±2 | 65±2 | 65±2 |
| Drive Method |
| Inverter Start |
| Eletric | (V/PH/HZ) | 380V/50HZ |
|
|
|
|
| | Length | 800 | 1080 | 1080 | 1380 | 1380 |
| Width | 700 | 750 | 750 | 850 | 850 |
| Height | 930 | 1000 | 1000 | 1100 | 1100 |
| Weight | (KG) | 190 | 310 | 320 | 410 | 460 |
| Outlet thread(inch/mm) | G1/2 | G3/4 | G3/4 | G1 | G1 |
